HYDSUNRIDA LD-P7D3R1A9A2B00 High Pressure Variable Piston Pump | 57799322 Russia Mining 119cc Replacement Pump

HYDSUNRIDA LD-P7D3R1A9A2B00 High Pressure Variable Piston Pump | 57799322 Russia Mining 119cc Replacement Pump

1. Product Overview

HYDSUNRIDA LD-P7D3R1A9A2B00 variable piston pump (Part No. 57799322) is a high-performance replacement solution tailored for Russia’s extreme mining environments. Featuring 119cc/r large displacement and 345bar ultra-high pressure resistance, it delivers stable, continuous heavy-duty output for 24-hour non-stop mining operation.Validated by 7 years of field iteration and mass production, this pump supports1:1 full interchangeability with original imported units in overall dimensions, flange installation, oil port layout and electronic control logic. It enables plug-and-play replacement with no equipment modification or parameter debugging, effectively solving common defects of ordinary replacement pumps such as low-temperature startup failure and high-pressure pressure drop.All LD-P7D3 pumps are ISO9001:2015 and SGS certified. Every unit undergoes strict high-pressure impact, leakage and endurance testing before delivery, guaranteeing stable and durable performance under -40℃ ultra-cold and high-dust harsh mining conditions.

2. Full Compatible Model Range

The LD-P7D series features three standardized upgraded versions to match diverse Russian mining working conditions, plus customizable solutions for special scenarios, ensuring zero-error replacement:

• 4A Standard Electronic Control (Temperate Mining Area): LD-P7D2R1A4A2B00, LD-P7D3R1A4A2B00, LD-P7D4R1A4A2B00

• 8A Heavy-duty Electronic Control (High-impact Working Condition): LD-P7D2R1A8A2B00, LD-P7D3R1A8A2B00, LD-P7D4R1A8A2B00

• 9A Extreme Cold Electronic Control (Russia Bestseller): LD-P7D2R1A9A2B00, LD-P7D3R1A9A2B00, LD-P7D4R1A9A2B00, LD-P7D5R1A9A2B00

• Non-standard Customization: Customizable pressure range, variable response and sealing structure for ultra-low temperature and super heavy-load working conditions

3. Core Technical Parameters

All technical parameters strictly comply with original factory standards. The replacement pump maintains identical power, flow and low-temperature performance as original equipment, with zero power attenuation and no compatibility risks.

4. Product Core Advantages

Optimized exclusively for Russian extreme mining conditions, LD-P7D3 piston pumps deliver import-equivalent performance, flexible supply capacity and outstanding cost performance. The core advantages are summarized as follows:

• 7-year Mature Field Verification: Iteratively upgraded and mass-produced for 7 years, all pumps adopt precision machining and one-by-one high-pressure calibration. Effectively avoid common faults like pressure drop, low-temperature stalling, oil leakage and early wear, ensuring long-term stable heavy-load operation.

• 1:1 Lossless Plug-and-play Replacement: Fully consistent with original pumps in structure, installation and electronic control parameters. No equipment modification or debugging required, maintaining original equipment working efficiency without power attenuation.

• Strict Multi-process Quality Control: Certified by ISO9001 and SGS international standards. Each finished unit passes peak pressure impact, long-duration endurance, anti-leakage sealing and precise parameter calibration tests, fully adapting to Russia’s extreme cold, dusty and high-impact mining scenarios.

• Manufacturer sells directly, highly competitive market pricing & Fast Delivery: Factory direct sales eliminate intermediate markup. Adequate spot stock and stable production effectively solve the pain points of long import lead time and unstable supply, supporting long-term bulk orders and large-scale mining project cooperation.

• Customizable Extreme Condition Solutions: Support OEM & ODM personalized customization for Siberian ultra-cold, Far East open-air and heavy-duty mining scenarios. Adjustable pressure range, response parameters and sealing configurations, with complete supporting hydraulic components to realize one-stop system matching.

• Mature Russian Mining Export Experience: As the core export model for Russian mining areas, the exclusive 9A extreme cold version adapts to full regional extreme working conditions. Complete bilingual export documents ensure smooth customs clearance, with high overseas repurchase rate and stable market reputation.

5. Compatible Mining Equipment

This piston pump features wide compatibility with mainstream Epiroc and Atlas Copco mining equipment widely used in Russian mining areas, covering underground tunneling, open-pit drilling, mining air compressor and geological exploration scenarios:

• Epiroc Drill Jumbos: BOOMER 281, 282, 291, 292, E10, E20, S1 and full-series underground tunneling equipment, stable for low-temperature high-pressure operation.

• Epiroc Open-pit Drilling Rigs: FlexiROC T30, T40 R, T50, D65, PowerROC T35, T40 and other top hammer & down-the-hole drilling rigs, suitable for 24-hour heavy-load field operation.

• Atlas Copco Mining Air Compressors: XATS156C, XAHS166C, XAVS206C and other mobile air compressor hydraulic systems, maintaining stable power output under extreme conditions.

• Field Exploration Equipment: Compatible with core drilling, sampling drilling and pile foundation hydraulic units for wild and complex mining environments.

6. After-sales & Export Guarantee

We provide exclusive standardized after-sales and export services for the Russian market. All LD-P7D3 series pumps come with 12-month full machine warranty, with extended warranty available for core precision components. Our 7×24-hour multilingual technical team provides one-stop support including model selection verification, professional installation guidance, parameter debugging and rapid fault troubleshooting in English and Russian.Complete export qualification and customs clearance documents are fully prepared, supporting exclusive bulk price protection and priority production for large mining projects, ensuring stable and worry-free overseas project delivery.

7. Manufacturer Strength

HYDSUNRIDA focuses on the R&D, precision production and foreign trade export of high-pressure mining hydraulic pumps and motors, owning a complete industrial chain covering precision processing, automatic assembly and standardized strict testing.After 7 years of iterative optimization and field verification in Russia’s extreme mining environments, the P7D series has reached full import-level performance standards. With an annual output of tens of thousands of high-pressure piston pumps, strict independent quality control and short delivery cycles, we have established long-term stable cooperative relationships with major Russian mining areas and foreign trade enterprises.

8. Installation & Operation Notes

Standardized installation and operation specifications effectively avoid abnormal noise, pressure fluctuation, oil leakage and premature wear, greatly extending the service life of high-pressure mining piston pumps under extreme working conditions:

• Shaft Coaxiality Requirement: Keep the coaxiality error between the pump shaft and motor shaft within 0.1mm. Only use elastic coupling for connection. Rigid installation, offset and tilted assembly are forbidden to prevent shaft deformation, vibration and abnormal wear.

• Oil Suction Pipeline Standard: Ensure the suction pipeline is fully sealed, airtight and unobstructed. Air inhalation will cause pressure fluctuation, loud noise and excessive temperature rise. Regularly check pipeline aging and loose joints for stable system operation.

• Hydraulic Oil Cleanliness: Adopt qualified anti-wear hydraulic oil and keep the oil clean without metal debris, dust and turbidity. Impurities will scratch the internal pump core and cause internal leakage and pressure loss. Replace hydraulic oil and filter elements regularly.

• Pressure & Speed Limitation: Strictly prohibit long-term over-rated pressure, over-peak pressure and over-speed operation. Long-term overload operation will accelerate seal aging and pump core fatigue, leading to performance attenuation and shortened service life.

• Startup & Commissioning Rules: Bleed air completely before initial startup or hydraulic oil replacement. Operate the pump under no-load condition for 3–5 minutes, check for abnormal noise and stable pressure, then apply load gradually. Never start with full load to prevent instantaneous impact damage to internal components.

• Working Environment Adaptation: Ensure good ventilation and heat dissipation for the pump unit. Keep hydraulic oil temperature between 30℃–55℃. Avoid long-term exposure to high temperature, heavy dust and humid conditions to prevent seal aging and oil deterioration.
